• Country
• Soviet Union

• Manufacturer / Brand
• Unknown - CUSTOM BUILT: Soviet Union

• Year
• 1986

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 74624

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Details
• Power Supply (not only Batt.El.)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Material
• Metal case

• from Radiomuseum.org
• Model: Universalspeisequelle 2.087.008 RE - Unknown - CUSTOM BUILT: Soviet

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 300 x 120 x 200 mm / 11.8 x 4.7 x 7.9 inch

• Notes
• Regelbares, kurzschlußfestes Gleichspannungsnetzgerät, 0 - 15 V und 15 - 30 V, Strombegrenzung 1,5 A. Weiterhin Wechselspannungsabgänge 6,3/12,6 V (3 A) und 36 V (1,5 A). Für den Export nach Deutschland gebaut, Beschriftung in Deutsch.

• Net weight (2.2 lb = 1 kg)
• 5.5 kg / 12 lb 1.8 oz (12.115 lb)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by a member from D. See "Data change" for further contributors.
