Breitbandverstärker (Sender) 40757

Breitbandverstärker 40757; Valvo GmbH, (ID = 223448) RF-Ampl.

Breitbandverstärker 40757; Valvo GmbH, (ID = 223454) RF-Ampl.

Breitbandverstärker 40757; Valvo GmbH, (ID = 223456) RF-Ampl.

Breitbandverstärker 40757; Valvo GmbH, (ID = 223458) RF-Ampl.

Breitbandverstärker 40757; Valvo GmbH, (ID = 223450) RF-Ampl.

Breitbandverstärker 40757; Valvo GmbH, (ID = 223452) RF-Ampl.
Breitbandverstärker 40757; Valvo GmbH, (ID = 223447) RF-Ampl.
Use red slider bar for more.
Breitbandverstärker 40757; Valvo GmbH, (ID = 223447) RF-Ampl.
Valvo GmbH,: Breitbandverstärker 40757 [RF-Ampl.] ID = 223447 630x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Breitbandverstärker (Sender) 40757, Valvo GmbH, Radioröhrenfabrik; Hamburg

Country:  Germany
Manufacturer / Brand:  Valvo GmbH, Radioröhrenfabrik; Hamburg
Year: 1983 ?? Category: RF (Radio Frequency-) Amplifier
Valves / Tubes 1: YL1420
Main principle Radio Frequency Amplification only
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Powered by external power supply or a main unit.
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Breitbandverstärker 40757 - Valvo GmbH, Radioröhrenfabrik;
Material Metal case
Shape Boatanchor (heavy military or commercial set).
Dimensions (WHD) 500 x 700 x 500 mm / 19.7 x 27.6 x 19.7 inch
Notes Kanalabgestimmter Breitbandverstärker in Hohlraumtechnik für Bildsender in Gitterbasisschaltung im Bereich I.
Net weight (2.2 lb = 1 kg) 70 kg / 154 lb 3 oz (154.185 lb)
Mentioned in Valvo Senderöhren 1983

Model page created by a member from D. See "Data change" for further contributors.
