• Country
• Germany

• Manufacturer / Brand
• Valvo GmbH, Radioröhrenfabrik; Hamburg

• Year
• 1983 ??

• Category
• RF (Radio Frequency-) Amplifier

• Radiomuseum.org ID
• 98682

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• YL1590

• Main principle
• Radio Frequency Amplification only

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Powered by external power supply or a main unit.

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Breitbandverstärker 40782V - Valvo GmbH, Radioröhrenfabrik;

• Shape
• Boatanchor (heavy military or commercial set >20 kg).

• Dimensions (WHD)
• 190 x 637 x 270 mm / 7.5 x 25.1 x 10.6 inch

• Notes
• Kontinuierlich abstimmbarer Breitbandverstärker in Hohlraumtechnik für Bildsender und FS-Umsetzer in Gitterbasisschaltung im Bereich IV und V.

• Mentioned in
• Valvo Senderöhren 1983

• Author
• Model page created by a member from D. See "Data change" for further contributors.
