Luba 71PT

Luba 71PT; Vanguard; Hospitalet (ID = 1432172) Radio Luba 71PT; Vanguard; Hospitalet (ID = 1432173) Radio
Luba 71PT; Vanguard; Hospitalet (ID = 1432174) Radio Luba 71PT; Vanguard; Hospitalet (ID = 1432175) Radio
Luba 71PT; Vanguard; Hospitalet (ID = 1432176) Radio
Use red slider bar for more.
Luba 71PT; Vanguard; Hospitalet (ID = 1432172) Radio
Vanguard; Hospitalet: Luba 71PT [Radio] ID = 1432172 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model Luba 71PT, Vanguard; Hospitalet de Llobregat:
Propiedad de Jose Morell Borras (Coleccionista).

Country:  Spain
Manufacturer / Brand:  Vanguard; Hospitalet de Llobregat
alternative name

Cahué Industrial
Year: 1978 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: BF495 BF495 BF495 unknown_tr unknown_tr unknown_tr TBA120 TBA820
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries / 6 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Luba 71PT - Vanguard; Hospitalet de
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 225 x 130 x 50 mm / 8.9 x 5.1 x 2 inch
Net weight (2.2 lb = 1 kg) 0.950 kg / 2 lb 1.5 oz (2.093 lb)
Mentioned in RADIOS ESPAÑOLAS - Joan Julià Enrich

Model page created by Abel Cubas Torres. See "Data change" for further contributors.
