Midas 21PT-S2

Midas 21PT-S2; Vanguard; Hospitalet (ID = 284670) Radio
Midas 21PT-S2; Vanguard; Hospitalet (ID = 1615029) Radio Midas 21PT-S2; Vanguard; Hospitalet (ID = 1615032) Radio
Use red slider bar for more.
Midas 21PT-S2; Vanguard; Hospitalet (ID = 1615029) Radio
Vanguard; Hospitalet: Midas 21PT-S2 [Radio] ID = 1615029 541x439
Select picture or schematic to display from thumbnails on the right and click for download.
For model Midas 21PT-S2, Vanguard; Hospitalet de Llobregat:
Anuncio aparecido en la página veinticinco del periódico La Vanguardia Española el martes trece de agosto de 1963.

Country:  Spain
Manufacturer / Brand:  Vanguard; Hospitalet de Llobregat
alternative name

Cahué Industrial
Year: 1963 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: AF116 AF116 AF116 OC75 OC74 OC74 OA70
Main principle Super-Heterodyne (Super in general); 2 AF stage(s)
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Dry Batteries / 4 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Midas 21PT-S2 - Vanguard; Hospitalet de
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Price in first year of sale 2'420.00 ESP
Literature/Schematics (1) -- Schematic

Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
