VEF Radio Works: Kristall - Кристалл [Radio] ID = 258212 817x611

Select picture or schematic to display from thumbnails on the right and click for download.

For model Kristall - Кристалл, VEF Radio Works (Valst Elektrotechniska Fabrika, ВЕФ); Riga

Country:

Latvia (Latvia, Riga)

Manufacturer / Brand:

VEF Radio Works (Valst Elektrotechniska Fabrika, ВЕФ); Riga

Year: 1958

Category: Broadcast Receiver - or past WW2 Tuner

Valves / Tubes

14: 6Н3П 6И1П 6К4П 6К4П 6К4П 6Х2П 6Н1П 6Н2П 6Н2П 6П14П 6П14П 6П14П 6П14П 6Е1П

Main principle	Superheterodyne (common); ZF/IF 456 kHz
Wave bands	Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
Details
Power type and voltage	Alternating Current supply (AC) / 110, 127, 220 Volt
Loudspeaker	6 Loudspeakers
Power out
from Radiomuseum.org	Model: Kristall - Кристалл - VEF Radio Works Valst
Material	Wooden case
Shape	Tablemodel with Push Buttons.
Notes	Auto tuning with electro motor. Four butons fixed tone register. Model exibit in Brussels in 1958. In photos - radio set "Kristall" in see-throught (perspex) case, produced unitary, especially for 1958 Brussels Exhibition. Now this set in Atis Brikmanis old radio collection, Liepaja, Latvia.

Model page created by Zenonas Langaitis. See "Data change" for further contributors.

All listed radios etc. from VEF Radio Works (Valst Elektrotechniska Fabrika, ВЕФ); Riga
Here you find 139 models, 136 with images and 74 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.

Collection of Atis Brikmanis (LV)
