For model Vefsuper KB416 militär, VEF Radio Works (Valst Elektrotechniska Fabrika, ВЕФ); Riga

Country:  Latvia (Latvia, Riga)
Manufacturer / Brand:  VEF Radio Works (Valst Elektrotechniska Fabrika, ВЕФ); Riga
Year: 1941–1944 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: DK21 DF22 DBC21 DLL21
Main principle Superheterodyne (common); ZF/IF 469 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Storage and/or dry batteries / 2 & 90-120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 1.2 W (unknown quality)
from Radiomuseum.org Model: Vefsuper KB416 [militär] - VEF Radio Works Valst
Material Wooden case
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 340 x 270 x 165 mm / 13.4 x 10.6 x 6.5 inch
Notes siehe auch zivile Version des KB416. See also civilian version of KB416.
Net weight (2.2 lb = 1 kg) 7 kg / 15 lb 6.7 oz (15.419 lb)
Mentioned in - - Manufacturers Literature (Bedienungsanleitung 1942)

Model page created by Dirk Becker. See "Data change" for further contributors.
