For model Vega 206 VEF 206, Vega (brand), Technical and Optical Equipment Ltd.; London

Country:  Great Britain (UK)
Manufacturer / Brand:  Vega (brand), Technical and Optical Equipment Ltd.; London
Year: 1974 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10:
Main principle Super-Heterodyne (Super in general); ZF/IF 465 ± 2 kHz
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details
Power type and voltage Dry Batteries / 6 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 0.15 W (unknown quality)
from Radiomuseum.org Model: Vega 206 VEF 206 - Vega brand, Technical and
Material Moulded (Bakelite or Plastics)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 297 x 229 x 105 mm / 11.7 x 9 x 4.1 inch
Notes

This portable superhet receiver was advertised as having 23 transistors (integrated circuitry). It has 8 wavebands:

  • LW: 2000 - 735.4 m (150 - 408 kHz)
  • MW: 571.6 - 186.9 m (525 - 1605 kHz)
  • SW6: 60 - 150 m (2.0 - 5.0 MHz)
  • SW5: 41 m (5.0 - 7.5 MHz)
  • SW4: 25 m (9.3 - 12.1 MHz)
  • SW3: 19 m (15.1 - 15.45 MHz)
  • SW2: 16 m (17.7 - 17.9 MHz)
  • SW1: 13 m (21.45 - 21.75 MHz)

It features built-in ferrite rod and telescopic aerials, connectors for earphone (50 - 120 ohms impedance) and external loudspeaker (8 ohms impedance).

This radio is a rebranded version of model VEF 206 made by VEF in Latvia.

Made in USSR.

Net weight (2.2 lb = 1 kg) 2.7 kg / 5 lb 15.2 oz (5.947 lb)
Collectors' prices
Mentioned in -- Original prospect or advert

Model page created by Mark Hippenstiel. See "Data change" for further contributors.
