- Country
- Spain
- Manufacturer / Brand
- Vica (Talleres), Capdevila; Barcelona
- Year
- 1956 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 363705
todocoleccion.net 361021200 desconocido
todocoleccion.net 361021200 desconocido
todocoleccion.net 361021200 desconocido
todocoleccion.net 361021200 desconocido
todocoleccion.net 361021200 desconocido
todocoleccion.net 361021200 desconocido
todocoleccion.net 361021200 desconocido
- Number of Tubes
- 5
- Valves / Tubes
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Alternating Current supply (AC) / 125 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: 740 - Vica Talleres, Capdevila;
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 420 x 285 x 0 mm / 16.5 x 11.2 x 0 inch
- Notes
-
Vica, Talleres Capdevila; receptor 740
Medidas aproximadas (42 x 28,5 cm) tomadas del aparato
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
