Aida RA-6350S

Aida RA-6350S; Videoton; (ID = 428487) Radio Aida RA-6350S; Videoton; (ID = 713792) Radio
Aida RA-6350S; Videoton; (ID = 1643812) Radio Aida RA-6350S; Videoton; (ID = 1643814) Radio
Aida RA-6350S; Videoton; (ID = 1643816) Radio Aida RA-6350S; Videoton; (ID = 1643817) Radio
Aida RA-6350S; Videoton; (ID = 1643818) Radio Aida RA-6350S; Videoton; (ID = 1857987) Radio
Aida RA-6350S; Videoton; (ID = 1857988) Radio Aida RA-6350S; Videoton; (ID = 1857989) Radio
Use red slider bar for more.
Aida RA-6350S; Videoton; (ID = 428487) Radio
Videoton;: Aida RA-6350S [Radio] ID = 428487 800x261
Select picture or schematic to display from thumbnails on the right and click for download.
For model Aida RA-6350S, Videoton; Székesfehérvár

Country:  Hungary
Manufacturer / Brand:  Videoton; Székesfehérvár
Brand

VTTV
Year: 1980 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 31:
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 20 W (unknown quality)
from Radiomuseum.org Model: Aida RA-6350S - Videoton; Székesfehérvár
Material Wooden case
Shape Book-shelf unit.
Dimensions (WHD) 615 x 135 x 280 mm / 24.2 x 5.3 x 11 inch
Notes ICs: 7
FM: OIRT & CCIR.
Net weight (2.2 lb = 1 kg) 11 kg / 24 lb 3.7 oz (24.229 lb)
Price in first year of sale 7'580.00 HUF
Literature/Schematics (1) Kókai-Varsányi: Sztereó rádiók szervizkönyve, Budapest 1984.

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.



All listed radios etc. from Videoton; Székesfehérvár
Here you find 673 models, 629 with images and 176 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
