Camping Super BR114

Camping Super BR114; Videoton; (ID = 1465786) Radio

Camping Super BR114; Videoton; (ID = 1465787) Radio
Camping Super BR114; Videoton; (ID = 388658) Radio Camping Super BR114; Videoton; (ID = 1184453) Radio
Camping Super BR114; Videoton; (ID = 1184454) Radio Camping Super BR114; Videoton; (ID = 1184455) Radio
Camping Super BR114; Videoton; (ID = 1184456) Radio Camping Super BR114; Videoton; (ID = 1997653) Radio
Camping Super BR114; Videoton; (ID = 1997654) Radio Camping Super BR114; Videoton; (ID = 1997655) Radio
Camping Super BR114; Videoton; (ID = 1997656) Radio Camping Super BR114; Videoton; (ID = 1997658) Radio
Use red slider bar for more.
Camping Super BR114; Videoton; (ID = 388658) Radio
Videoton;: Camping Super BR114 [Radio] ID = 388658 500x368
Select picture or schematic to display from thumbnails on the right and click for download.
For model Camping Super BR114, Videoton; Székesfehérvár:
Quelle:The history of Hungarian radio Broadcasting and Catalogue of Radio Receivers. Thanks for technical assistance Első Zalai Rádiómúzeum Alapítvány ( radio-muzeum.hu), First Zala County Radio Museum Foundation, Hungary, Zalaegerszeg.

Country:  Hungary
Manufacturer / Brand:  Videoton; Székesfehérvár
Brand

VTTV
Year: 1969 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10: AF106 AF106 AF135 AF135 AF136 AF136 AC125 AC125 AC128 AC128
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 8 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Batteries / addl. power jack / 4 x 1,5 / 6 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1 W (unknown quality)
from Radiomuseum.org Model: Camping Super BR114 - Videoton; Székesfehérvár
Material Various materials
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 280 x 190 x 81 mm / 11 x 7.5 x 3.2 inch
Notes

Der Camping BR114 ist ein Reiseempfänger mit Anschlüssen für TA/ TB, ein externes Netzteil und für einen Aussenlautsprecher. FM von 63 - 74 MHz. oder 87,5 - 104 MHz.

Net weight (2.2 lb = 1 kg) 2.8 kg / 6 lb 2.7 oz (6.167 lb)
Source of data Radio es Televizio Vevö keszülekek 1967-69

Model page created by Karl Günther Goldsteiner. See "Data change" for further contributors.



All listed radios etc. from Videoton; Székesfehérvár
Here you find 673 models, 629 with images and 176 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
