Car Radio RD-3602

Car Radio RD-3602; Videoton; (ID = 1888774) Car Radio

Car Radio RD-3602; Videoton; (ID = 1888775) Car Radio
Car Radio RD-3602; Videoton; (ID = 1888795) Car Radio Car Radio RD-3602; Videoton; (ID = 1888796) Car Radio
Car Radio RD-3602; Videoton; (ID = 1888788) Car Radio Car Radio RD-3602; Videoton; (ID = 1888789) Car Radio
Car Radio RD-3602; Videoton; (ID = 1888790) Car Radio Car Radio RD-3602; Videoton; (ID = 1888791) Car Radio
Car Radio RD-3602; Videoton; (ID = 1888799) Car Radio Car Radio RD-3602; Videoton; (ID = 1888800) Car Radio
Car Radio RD-3602; Videoton; (ID = 1988460) Car Radio Car Radio RD-3602; Videoton; (ID = 1988461) Car Radio
Use red slider bar for more.
Car Radio RD-3602; Videoton; (ID = 1888795) Car Radio
Videoton;: Car Radio RD-3602 [Car Radio] ID = 1888795 933x919
Select picture or schematic to display from thumbnails on the right and click for download.
For model Car Radio RD-3602, Videoton; Székesfehérvár:
Thanks for Mr.Sik Béla, Hungary, Budapest and Első Zalai Rádiómúzeum Alapítvány, First Zala County Radio Museum Foundation.

Country:  Hungary
Manufacturer / Brand:  Videoton; Székesfehérvár
Brand

VTTV
Year: 1972–1975 Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 8: BF240 BF241 КТ315Б КТ315Б AC126 AD161 AD162
Main principle Superheterodyne (common)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: Car Radio RD-3602 - Videoton; Székesfehérvár
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 95 x 39 x 160 mm / 3.7 x 1.5 x 6.3 inch
Net weight (2.2 lb = 1 kg) 1.8 kg / 3 lb 15.4 oz (3.965 lb)
Source of data -- Original-techn. papers.
Mentioned in -- Schematic

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
