Hi-Fi Box DC-2012A

Hi-Fi Box DC-2012A; Videoton; (ID = 863526) Speaker-P Hi-Fi Box DC-2012A; Videoton; (ID = 863527) Speaker-P
Hi-Fi Box DC-2012A; Videoton; (ID = 1375697) Speaker-P Hi-Fi Box DC-2012A; Videoton; (ID = 1375698) Speaker-P
Hi-Fi Box DC-2012A; Videoton; (ID = 1375699) Speaker-P Hi-Fi Box DC-2012A; Videoton; (ID = 1375700) Speaker-P
Hi-Fi Box DC-2012A; Videoton; (ID = 1375701) Speaker-P
Use red slider bar for more.
Hi-Fi Box DC-2012A; Videoton; (ID = 863526) Speaker-P
Videoton;: Hi-Fi Box DC-2012A [Speaker-P] ID = 863526 800x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model Hi-Fi Box DC-2012A, Videoton; Székesfehérvár:
Thanks for Mr.Laczi Péter, Hungary!

Country:  Hungary
Manufacturer / Brand:  Videoton; Székesfehérvár
Brand

VTTV
Year: 1980 ? Category: Loudspeaker, headphone or earphone
Wave bands - without
Details
Power type and voltage No Power needed
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: Hi-Fi Box DC-2012A - Videoton; Székesfehérvár
Material Wooden case
Dimensions (WHD) 260 x 480 x 258 mm / 10.2 x 18.9 x 10.2 inch
Notes 45/60 Watt 4 ohm 45 Hz-20 kHz 20 cm woofer, 10 cm midrange, 1" dome tweeter. Passive, closed box, acoustic suspension.
Price in first year of sale 1'400.00 HUF
Source of data -- Original prospect or advert

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
