For model Mobilette TB684, Videoton; Székesfehérvár:
Radio es TVkeszulekek, 1967-69, Kadar G. 1970

Country:  Hungary
Manufacturer / Brand:  Videoton; Székesfehérvár
Brand

VTTV
Year: 1968 Category: Television Receiver (TV) or Monitor
Valves / Tubes 12: PCC189 PCF80 PCF200 PCF201 PCF80 PCL84 PCL85 PCL86 PL500 PY88 DY86 A47-17W
Main principle Superheterodyne (common); ZF/IF 38900 kHz
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 18 cm = 7.1 inch
Power out 1.2 W (unknown quality)
from Radiomuseum.org Model: Mobilette TB684 - Videoton; Székesfehérvár
Material Various materials
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 530 x 410 x 230 mm / 20.9 x 16.1 x 9.1 inch
Notes VHF-UHF OIRT, Speaker: 120×180 mm. Picture tube:47 cm.
Net weight (2.2 lb = 1 kg) 17 kg / 37 lb 7.1 oz (37.445 lb)
Source of data Radio es Televizio Vevö keszülekek 1967-69

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
