RD-4614

RD-4614; Videoton; (ID = 267510) Car Radio

RD-4614; Videoton; (ID = 267511) Car Radio
RD-4614; Videoton; (ID = 1876453) Car Radio RD-4614; Videoton; (ID = 388669) Car Radio
RD-4614; Videoton; (ID = 709224) Car Radio RD-4614; Videoton; (ID = 713434) Car Radio
RD-4614; Videoton; (ID = 713813) Car Radio RD-4614; Videoton; (ID = 1086153) Car Radio
RD-4614; Videoton; (ID = 1876452) Car Radio RD-4614; Videoton; (ID = 1876454) Car Radio
RD-4614; Videoton; (ID = 1876491) Car Radio RD-4614; Videoton; (ID = 1991901) Car Radio
Use red slider bar for more.
RD-4614; Videoton; (ID = 1876453) Car Radio
Videoton;: RD-4614 [Car Radio] ID = 1876453 1400x538
Select picture or schematic to display from thumbnails on the right and click for download.
For model RD-4614, Videoton; Székesfehérvár:
Thanks for Mr.József Borsos, Hungary, Dunaújváros and Első Zalai Rádiómúzeum Alapítvány, First Zala County Radio Museum Foundation.

Country:  Hungary
Manufacturer / Brand:  Videoton; Székesfehérvár
Brand

VTTV
Year: 1982–1985 Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 8:
Main principle Superheterodyne (common); ZF/IF 465/10700 kHz
Tuned circuits 6 AM circuit(s)     7 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 3 W (unknown quality)
from Radiomuseum.org Model: RD-4614 - Videoton; Székesfehérvár
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 178 x 44 x 126 mm / 7 x 1.7 x 5 inch
Notes ICs: TAA691, TBA810A; UKW-Bereich 68-73 MHz (OIRT) und 87,5-104 MHz (CCIR).
Net weight (2.2 lb = 1 kg) 1 kg / 2 lb 3.2 oz (2.203 lb)
Price in first year of sale 2'120.00 HUF
Mentioned in Radio- es TV- kapcsolások, 1975-77
Literature/Schematics (1) Dániel József, Autórádiók szervizkönyve, Bp. 1988.

Model page created by Karl Günther Goldsteiner. See "Data change" for further contributors.



All listed radios etc. from Videoton; Székesfehérvár
Here you find 676 models, 632 with images and 176 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
