Riviera RB2603OCR

Riviera RB2603OCR; Videoton; (ID = 235738) Radio

Riviera RB2603OCR; Videoton; (ID = 235739) Radio
Riviera RB2603OCR; Videoton; (ID = 505774) Radio Riviera RB2603OCR; Videoton; (ID = 505778) Radio
Riviera RB2603OCR; Videoton; (ID = 505775) Radio Riviera RB2603OCR; Videoton; (ID = 505776) Radio
Riviera RB2603OCR; Videoton; (ID = 505777) Radio Riviera RB2603OCR; Videoton; (ID = 505779) Radio
Riviera RB2603OCR; Videoton; (ID = 505780) Radio Riviera RB2603OCR; Videoton; (ID = 613436) Radio
Riviera RB2603OCR; Videoton; (ID = 613437) Radio Riviera RB2603OCR; Videoton; (ID = 1629137) Radio
Use red slider bar for more.
Riviera RB2603OCR; Videoton; (ID = 505774) Radio
Videoton;: Riviera RB2603OCR [Radio] ID = 505774 753x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Riviera RB2603OCR, Videoton; Székesfehérvár:
Thanks for technical assistance Első Zalai Rádiómúzeum Alapítvány ( radio-muzeum.hu), First Zala County Radio Museum Foundation, Hungary, Zalaegerszeg.

Country:  Hungary
Manufacturer / Brand:  Videoton; Székesfehérvár
Brand

VTTV
Year: 1968–1971 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10:
Main principle Superheterodyne (common); ZF/IF 455/10700 kHz
Wave bands Broadcast, Short Wave plus FM or UHF.
Details
Power type and voltage Dry Batteries / 6 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 10 inch = 25.4 cm
Power out 0.5 W (unknown quality)
from Radiomuseum.org Model: Riviera RB2603OCR - Videoton; Székesfehérvár
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 254 x 160 x 59 mm / 10 x 6.3 x 2.3 inch
Notes KW-Bereich 5,9-12,2 MHz; UKW 66-100 MHz. Eisenlose Endstufe.
Net weight (2.2 lb = 1 kg) 1.5 kg / 3 lb 4.9 oz (3.304 lb)
Source of data Radio es Televizio Vevö keszülekek 1970-71
Literature/Schematics (1) Rences Tamás: Rádió Kapcsolások II., 1975.

Model page created by Karl Günther Goldsteiner. See "Data change" for further contributors.
