Saturnus RA4311S

Saturnus RA4311S; Videoton; (ID = 1182996) Radio Saturnus RA4311S; Videoton; (ID = 1072558) Radio
Saturnus RA4311S; Videoton; (ID = 1182997) Radio Saturnus RA4311S; Videoton; (ID = 1648707) Radio
Saturnus RA4311S; Videoton; (ID = 1648706) Radio Saturnus RA4311S; Videoton; (ID = 713369) Radio
Saturnus RA4311S; Videoton; (ID = 1072559) Radio Saturnus RA4311S; Videoton; (ID = 1182998) Radio
Saturnus RA4311S; Videoton; (ID = 1648708) Radio Saturnus RA4311S; Videoton; (ID = 1650282) Radio
Use red slider bar for more.
Saturnus RA4311S; Videoton; (ID = 1182996) Radio
Videoton;: Saturnus RA4311S [Radio] ID = 1182996 933x307
Select picture or schematic to display from thumbnails on the right and click for download.
For model Saturnus RA4311S, Videoton; Székesfehérvár:
Thanks for Első Zalai Rádiómúzeum Alapítvány, First Zala County Radio Museum Foundation, Hungary, Zalaegerszeg.

Country:  Hungary
Manufacturer / Brand:  Videoton; Székesfehérvár
Brand

VTTV
Year: 1975–1979 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10:
Main principle Superheterodyne (common); ZF/IF 455/10700 kHz
Wave bands Broadcast, 2 Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Saturnus RA4311S - Videoton; Székesfehérvár
Material Various materials
Shape Book-shelf unit.
Dimensions (WHD) 650 x 170 x 170 mm / 25.6 x 6.7 x 6.7 inch
Notes 4 IC, FM:66-104 MHz. 1 built speaker.
Net weight (2.2 lb = 1 kg) 5.5 kg / 12 lb 1.8 oz (12.115 lb)
Literature/Schematics (1) Kókai-Varsányi: Sztereo rádiók szervizkönyve, Budapest 1982.

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.



All listed radios etc. from Videoton; Székesfehérvár
Here you find 672 models, 627 with images and 174 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
