Speaker H 1218/10

Speaker H 1218/10; Videoton; (ID = 1055558) Speaker-P Speaker H 1218/10; Videoton; (ID = 1055559) Speaker-P
Speaker H 1218/10; Videoton; (ID = 1055560) Speaker-P Speaker H 1218/10; Videoton; (ID = 815951) Speaker-P
Speaker H 1218/10; Videoton; (ID = 844528) Speaker-P Speaker H 1218/10; Videoton; (ID = 1055561) Speaker-P
Use red slider bar for more.
Speaker H 1218/10; Videoton; (ID = 1055558) Speaker-P
Videoton;: Speaker H 1218/10 [Speaker-P] ID = 1055558 933x681
Select picture or schematic to display from thumbnails on the right and click for download.
For model Speaker H 1218/10, Videoton; Székesfehérvár

Country:  Hungary
Manufacturer / Brand:  Videoton; Székesfehérvár
Brand

VTTV
Year: 1962 ?? Category: Loudspeaker, headphone or earphone
Wave bands - without
Details
Power type and voltage No Power needed
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Speaker H 1218/10 - Videoton; Székesfehérvár
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 180 x 120 x 64 mm / 7.1 x 4.7 x 2.5 inch
Notes 2,5 VA / 4 Ohm, BaFe, 23800 Maxwell, 9500 Gauss. 80-15000 Hz.
Net weight (2.2 lb = 1 kg) 0.5 kg / 1 lb 1.6 oz (1.101 lb)
Source of data -- Original-techn. papers.

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
