Star De luxe RM 4624 A

Star De luxe RM 4624 A; Videoton; (ID = 1223261) Radio Star De luxe RM 4624 A; Videoton; (ID = 1471264) Radio
Star De luxe RM 4624 A; Videoton; (ID = 1471265) Radio Star De luxe RM 4624 A; Videoton; (ID = 1471266) Radio
Star De luxe RM 4624 A; Videoton; (ID = 1641624) Radio Star De luxe RM 4624 A; Videoton; (ID = 1641625) Radio
Star De luxe RM 4624 A; Videoton; (ID = 1641626) Radio Star De luxe RM 4624 A; Videoton; (ID = 1641628) Radio
Star De luxe RM 4624 A; Videoton; (ID = 1641629) Radio Star De luxe RM 4624 A; Videoton; (ID = 1752203) Radio
Use red slider bar for more.
Star De luxe RM 4624 A; Videoton; (ID = 1223261) Radio
Videoton;: Star De luxe RM 4624 A [Radio] ID = 1223261 444x288
Select picture or schematic to display from thumbnails on the right and click for download.
For model Star De luxe RM 4624 A, Videoton; Székesfehérvár:
Bild von Wolfgang Bauer.

Country:  Hungary
Manufacturer / Brand:  Videoton; Székesfehérvár
Brand

VTTV
Year: 1977 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 14:
Main principle Superheterodyne (common); ZF/IF 465/10700 kHz
Wave bands Broadcast, 2 Short Wave plus FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 220 / 6 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 3.5 W (unknown quality)
from Radiomuseum.org Model: Star De luxe RM 4624 A - Videoton; Székesfehérvár
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 345 x 210 x 92 mm / 13.6 x 8.3 x 3.6 inch
Notes Star De Luxe RM 4624 tuning variation (new transistor types). 2 IC-s, FM: OIRT & CCIR.
Net weight (2.2 lb = 1 kg) 3.9 kg / 8 lb 9.4 oz (8.59 lb)
Source of data -- Collector info (Sammler)

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
