Super Star TC-2613

Super Star TC-2613; Videoton; (ID = 1458175) Television

Super Star TC-2613; Videoton; (ID = 1458176) Television

Super Star TC-2613; Videoton; (ID = 1458177) Television

Super Star TC-2613; Videoton; (ID = 1458322) Television

Super Star TC-2613; Videoton; (ID = 1458323) Television

Super Star TC-2613; Videoton; (ID = 1458324) Television

Super Star TC-2613; Videoton; (ID = 1458325) Television

Super Star TC-2613; Videoton; (ID = 1458326) Television

Super Star TC-2613; Videoton; (ID = 1458327) Television

Super Star TC-2613; Videoton; (ID = 1458328) Television
Super Star TC-2613; Videoton; (ID = 714125) Television
Use red slider bar for more.
Super Star TC-2613; Videoton; (ID = 714125) Television
Videoton;: Super Star TC-2613 [Television] ID = 714125 933x494
Select picture or schematic to display from thumbnails on the right and click for download.
For model Super Star TC-2613, Videoton; Székesfehérvár:
Original prospect.

Country:  Hungary
Manufacturer / Brand:  Videoton; Székesfehérvár
Brand

VTTV
Year: 1982 ? Category: Television Receiver (TV) or Monitor
Valves / Tubes 1: 44ЛК2Б
Semiconductors (the count is only for transistors) 13: BF960 BF961 BF961 BF970 BF606 BF199 BF458 BC337 BU407 BD244 BC327 BC337 TDA440 TBA120 TBA800 TBA950 TDA1170
Main principle Superheterodyne (common); ZF/IF 38900 kHz
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 0.8 W (unknown quality)
from Radiomuseum.org Model: Super Star TC-2613 - Videoton; Székesfehérvár
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 490 x 355 x 310 mm / 19.3 x 14 x 12.2 inch
Notes

Der Super Star TC2613 empfängt VHF und UHF nach OIRT/ CCIR und hat 8 Speicherplätze.

Source of data -- Original prospect or advert

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
