Verona de Luxe RA3313G

Verona de Luxe RA3313G; Videoton; (ID = 267490) Radio

Verona de Luxe RA3313G; Videoton; (ID = 267491) Radio
Verona de Luxe RA3313G; Videoton; (ID = 2483225) Radio Verona de Luxe RA3313G; Videoton; (ID = 1184467) Radio
Verona de Luxe RA3313G; Videoton; (ID = 2403705) Radio Verona de Luxe RA3313G; Videoton; (ID = 2403707) Radio
Verona de Luxe RA3313G; Videoton; (ID = 1076490) Radio Verona de Luxe RA3313G; Videoton; (ID = 388675) Radio
Verona de Luxe RA3313G; Videoton; (ID = 1076487) Radio Verona de Luxe RA3313G; Videoton; (ID = 1076491) Radio
Verona de Luxe RA3313G; Videoton; (ID = 1076493) Radio Verona de Luxe RA3313G; Videoton; (ID = 1184465) Radio
Use red slider bar for more.
Verona de Luxe RA3313G; Videoton; (ID = 2483225) Radio
Videoton;: Verona de Luxe RA3313G [Radio] ID = 2483225 1400x1269
Select picture or schematic to display from thumbnails on the right and click for download.
For model Verona de Luxe RA3313G, Videoton; Székesfehérvár

Country:  Hungary
Manufacturer / Brand:  Videoton; Székesfehérvár
Brand

VTTV
Year: 1971–1975 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: TAA691 TBA810
Main principle Superheterodyne (common); ZF/IF 465/10700 kHz
Wave bands Broadcast, Short Wave plus FM or UHF.
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 3 W (unknown quality)
from Radiomuseum.org Model: Verona de Luxe RA3313G - Videoton; Székesfehérvár
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 560 x 190 x 385 mm / 22 x 7.5 x 15.2 inch
Notes UKW-Bereich 65,8-77,5 MHz. KW Bereich 5,95-6,3 MHz. Phono-Chassis = Supraphon HC07.
Net weight (2.2 lb = 1 kg) 9 kg / 19 lb 13.2 oz (19.824 lb)
Price in first year of sale 2'940.00 HUF
Mentioned in Radio es Televizio Vevö keszülekek 1972-75

Model page created by Karl Günther Goldsteiner. See "Data change" for further contributors.
