RB1

RB1; Visseaux / Télévisso (ID = 1888746) Radio RB1; Visseaux / Télévisso (ID = 2510474) Radio
RB1; Visseaux / Télévisso (ID = 1888747) Radio
Use red slider bar for more.
RB1; Visseaux / Télévisso (ID = 1888746) Radio
Visseaux / Télévisso: RB1 [Radio] ID = 1888746 655x479
Select picture or schematic to display from thumbnails on the right and click for download.
For model RB1, Visseaux / Télévisso; Lyon / Paris:
Depliant modèles RB1-RB5

Country:  France
Manufacturer / Brand:  Visseaux / Télévisso; Lyon / Paris
Year: 1955 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6AJ8 6N6 6AV6 6BQ5 6V4
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 cm = 4.7 inch
Power out
from Radiomuseum.org Model: RB1 - Visseaux / Télévisso; Lyon /
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 365 x 225 x 165 mm / 14.4 x 8.9 x 6.5 inch
Notes

4 gammes d'ondes dont 1 bande étalée (BE). Cadre magnétique et antenne OC-BE incorporés.

Net weight (2.2 lb = 1 kg) 4.9 kg / 10 lb 12.7 oz (10.793 lb)
Price in first year of sale 20'600.00 FRF
Mentioned in -- Original prospect or advert
Literature/Schematics (1) - - Manufacturers Literature (Tarif Juillet 1955)

Model page created by John Koster. See "Data change" for further contributors.



All listed radios etc. from Visseaux / Télévisso; Lyon / Paris
Here you find 58 models, 38 with images and 10 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
