Automatic Record Changer 625
V-M (VM) (Voice of Music) Corporation; Benton Harbor (MI)
- Country
- United States of America (USA)
- Manufacturer / Brand
- V-M (VM) (Voice of Music) Corporation; Benton Harbor (MI)
- Year
- 1957 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 271684
Aus Photofact Folder
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Valves / Tubes
- 25L6GT
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 110-125 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.25 inch = 13.3 cm
- Material
- Various materials
- from Radiomuseum.org
- Model: Automatic Record Changer 625 - V-M VM Voice of Music
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Notes
-
The Voice of Music 625 is an AC operated 1 tube mono 45 R.P.M. only record player with automatic record changer. Has selenium rectifier in power supply. The record changer is similar to the RCA model RP-190 series.
- Mentioned in
- Photofact Folder, Howard W. SAMS (Set 351, Folder 19, Date 3-57)
- Author
- Model page created by Arpad Roth † 27.3.17. See "Data change" for further contributors.
