CR-708

CR-708; Volvo AB Now Volvo (ID = 2453426) Car Radio CR-708; Volvo AB Now Volvo (ID = 2453430) Car Radio
CR-708; Volvo AB Now Volvo (ID = 2453427) Car Radio CR-708; Volvo AB Now Volvo (ID = 2453428) Car Radio
CR-708; Volvo AB Now Volvo (ID = 2453432) Car Radio CR-708; Volvo AB Now Volvo (ID = 2453433) Car Radio
CR-708; Volvo AB Now Volvo (ID = 2453437) Car Radio CR-708; Volvo AB Now Volvo (ID = 2453431) Car Radio
Use red slider bar for more.
CR-708; Volvo AB Now Volvo (ID = 2453426) Car Radio
Volvo AB Now Volvo: CR-708 [Car Radio] ID = 2453426 1400x484
Select picture or schematic to display from thumbnails on the right and click for download.
For model CR-708, Volvo AB (Now Volvo Group); Göteborg

Country:  Sweden
Manufacturer / Brand:  Volvo AB (Now Volvo Group); Göteborg
Year: 1991 ? Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superhet with RF-stage
Wave bands Broadcast, Long Wave and FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Direct Current supply (DC) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 16 W (unknown quality)
from Radiomuseum.org Model: CR-708 - Volvo AB Now Volvo Group;
Material Various materials
Shape Chassis only or for «building in»
Dimensions (WHD) 185 x 60 x 180 mm / 7.3 x 2.4 x 7.1 inch
Notes

Output power 2 x 8 W, 4 Ω.

Auto-reverse cassette.

Made in Japan

Net weight (2.2 lb = 1 kg) 1.430 kg / 3 lb 2.4 oz (3.15 lb)

Model page created by Carlos Saavedra. See "Data change" for further contributors.
