• Country
• Germany

• Manufacturer / Brand
• Wandel & Goltermann; Reutlingen

• Year
• 1960 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 114999

• • alternative name: Wago Wandel & Goltermann

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• No Power needed

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Abschwächer RT-1 - Wandel & Goltermann;

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 85 x 65 x 90 mm / 3.3 x 2.6 x 3.5 inch

• Notes
• Einstellbarer Abschwächer 0-60 dB, a0 = 10 dB, max. Eigangsleistung: 2 W, Z = 60 Ohm.

• Net weight (2.2 lb = 1 kg)
• 0.8 kg / 1 lb 12.2 oz (1.762 lb)

• Source of data
• - - Data from my own collection

• Author
• Model page created by a member from D. See "Data change" for further contributors.
