Wechselspannungs-Stabilisator WS-10

• Country
• Germany

• Manufacturer / Brand
• Wandel & Goltermann; Reutlingen

• Year
• 1981 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 124907

• • alternative name: Wago Wandel & Goltermann

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 0

• Valves / Tubes
• KL100

• Number of Transistors
• 18

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Wechselspannungs-Stabilisator WS-10 - Wandel & Goltermann;

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 478 x 244 x 407 mm / 18.8 x 9.6 x 16 inch

• Notes

• Leistungsbereich, bei 3000 VA Regelbereich 187...242 V. Ausgangsspannung 220 V ~ Fehler +- < 1 %, Regelzeitkonstante ca. 0,05 sec. Mit eingebauter Kaltleiter - Brücke.

• Net weight (2.2 lb = 1 kg)
• 36 kg / 79 lb 4.7 oz (79.295 lb)

• Literature/Schematics (1)
• -- Schematic

• Literature/Schematics (2)
• Wandel & Goltermann Katalog 1981

• Author
• Model page created by Karlheinz Fischer. See "Data change" for further contributors.
