DC Power Supply NPS605W

DC Power Supply NPS605W; Wanptek Electronic (ID = 2581733) Power-S
Use red slider bar for more.
DC Power Supply NPS605W; Wanptek Electronic (ID = 2581733) Power-S
Wanptek Electronic: DC Power Supply NPS605W [Power-S] ID = 2581733 600x905
Select picture or schematic to display from thumbnails on the right and click for download.
For model DC Power Supply NPS605W, Wanptek Electronic Co., Ltd.; Shenzhen

Country:  People's Republic of China
Manufacturer / Brand:  Wanptek Electronic Co., Ltd.; Shenzhen
Year: 2000 ?? Category: Power supply/conditioner or battery or charger
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 230 or 115 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: DC Power Supply NPS605W - Wanptek Electronic Co., Ltd.;
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 70 x 130 x 230 mm / 2.8 x 5.1 x 9.1 inch
Notes

Switching type Power Supply; Input AC Voltage at 230V +/- 10%, 50Hz (can be customized to 115V +/- 10%, 60Hz); Efficiency Rate up to 70%; Output Voltage ranges from zero to 60 VDC with continuous adjustment; Recovery Time <= 500 microseconds; Voltage Stability 0,1% +/- 3 mV; Ripple 0,5% Vp-p; Voltage Display Resolution  0,1 V; Current Display Resolution 0,01 A; Power Display Resolution 0,1 W.

Net weight (2.2 lb = 1 kg) 1.4 kg / 3 lb 1.3 oz (3.084 lb)
Mentioned in -- Original prospect or advert

Model page created by Emilio Focosi. See "Data change" for further contributors.
