A-20, C-5
Waveforms, Inc.; New York, NY
- Country
- United States of America (USA)
- Manufacturer / Brand
- Waveforms, Inc.; New York, NY
- Year
- 1953 ?
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 360799
Picture from service manual.
picture from service manual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 60Hz, 117V=110-120 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Material
- Metal case
- from Radiomuseum.org
- Model: A-20, C-5 - Waveforms, Inc.; New York, NY
- Shape
- Chassis only or for «building in»
- Notes
-
Waveforms model A20, C-5 is an AC operated pre-amp & audio amplifier.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 191, folder 20, dated 1-53)
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
