Integrated Head Amp Modul 42V

Integrated Head Amp Modul 42V; Wega, (ID = 2013797) Ampl/Mixer

Integrated Head Amp Modul 42V; Wega, (ID = 2013798) Ampl/Mixer

Integrated Head Amp Modul 42V; Wega, (ID = 2013799) Ampl/Mixer

Integrated Head Amp Modul 42V; Wega, (ID = 2013800) Ampl/Mixer

Integrated Head Amp Modul 42V; Wega, (ID = 2013801) Ampl/Mixer

Integrated Head Amp Modul 42V; Wega, (ID = 2013803) Ampl/Mixer

Integrated Head Amp Modul 42V; Wega, (ID = 2013804) Ampl/Mixer

Integrated Head Amp Modul 42V; Wega, (ID = 2013805) Ampl/Mixer

Integrated Head Amp Modul 42V; Wega, (ID = 2013806) Ampl/Mixer
Integrated Head Amp Modul 42V; Wega, (ID = 2024147) Ampl/Mixer Integrated Head Amp Modul 42V; Wega, (ID = 1573983) Ampl/Mixer
Integrated Head Amp Modul 42V; Wega, (ID = 1573984) Ampl/Mixer Integrated Head Amp Modul 42V; Wega, (ID = 1976690) Ampl/Mixer
Integrated Head Amp Modul 42V; Wega, (ID = 2024146) Ampl/Mixer Integrated Head Amp Modul 42V; Wega, (ID = 2024148) Ampl/Mixer
Integrated Head Amp Modul 42V; Wega, (ID = 2024149) Ampl/Mixer Integrated Head Amp Modul 42V; Wega, (ID = 2024150) Ampl/Mixer
Use red slider bar for more.
Integrated Head Amp Modul 42V; Wega, (ID = 2024147) Ampl/Mixer
Wega,: Integrated Head Amp Modul 42V [Ampl/Mixer] ID = 2024147 1400x775
Select picture or schematic to display from thumbnails on the right and click for download.
For model Integrated Head Amp Modul 42V, Wega, Württembergische Radio-Ges. mbH; Stuttgart, Fellbach:
Ebay Auction

Country:  Germany
Manufacturer / Brand:  Wega, Württembergische Radio-Ges. mbH; Stuttgart, Fellbach
alternative name

Württemb. Radio-Ges.mbH; Stuttgart
Year: 1979 Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 180 W (undistorted)
from Radiomuseum.org Model: Integrated Head Amp Modul 42V - Wega, Württembergische Radio-
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 360 x 150 x 260 mm / 14.2 x 5.9 x 10.2 inch
Notes

WEGA Stereo Integrated Amplifier Model Modul 42V.
Power output:
90 Watts RMS per channel into 4Ω (stereo)
120 Watts Musicpower per channel into 4Ω (stereo)
Frequency response: 10Hz to 50kHz
Input sensitivity: 0.12mV (MC), 2.5mV (MM), 150mV (line)
Signal to noise ratio: 70dB (MC), 75dB (MM), 90dB (line)
Output: 0.9V (Pre out)
Speaker load impedance: 4Ω to 16Ω
Treble- and Bass Control
Loudness
Muting
Hi- & Subsonic Filter
Audio Peak Power Display
Power Consumption max. 380 Watts
Finish in Black or in Grey
Note:
Part of the WEGA HiFi System Modul 42


Mentioned in - - Manufacturers Literature (Service Manual)

Model page created by Gerhard Wickern. See "Data change" for further contributors.
