For model HiFi Cassette Deck Modul 42 C, Wega, Württembergische Radio-Ges. mbH; Stuttgart, Fellbach:
Ebay-Verk.: rheingeist, ArtNr.: 322672570069

Country:  Germany
Manufacturer / Brand:  Wega, Württembergische Radio-Ges. mbH; Stuttgart, Fellbach
alternative name

Württemb. Radio-Ges.mbH; Stuttgart
Year: 1978 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 39:
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player; Hi-Fi equipment
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: HiFi Cassette Deck Modul 42 C - Wega, Württembergische Radio-
Material Various materials
Shape Book-shelf unit.
Dimensions (WHD) 360 x 150 x 260 mm / 14.2 x 5.9 x 10.2 inch
Notes

HiFi-Stereo-Cassetten-Recorder. Übertragungsbereich mit FeCr-Band: 30···15500 Hz. Gehäusefarbe: schwarz oder hellgrau. Nachfolgemodell des Modul 41 C. Augenfälligste Änderung gegenüber dem Vorgängermodell ist die Aussteuerungsanzeige mit Hilfe von Leuchtdiodenketten.

Mentioned in -- Original prospect or advert
Literature/Schematics (1) Funkschau (22/1978, S. 1070)

Model page created by Gerhard Wickern. See "Data change" for further contributors.
