• Year
  • 1970/1971
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 28077
    • alternative name: Württemb. Radio-Ges.mbH; Stuttgart

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 50
  • Semiconductors
  • Main principle
  • Superheterodyne (common); ZF/IF 460/10700 kHz
  • Tuned circuits
  • 7 AM circuit(s)     16 FM circuit(s)
  • Wave bands
  • Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
  • Details
  • Changer (Record changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: HiFi-Musikstudio 3205 [Nussb.] - Wega, Württembergische Radio-
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 776 x 172 x 389 mm / 30.6 x 6.8 x 15.3 inch
  • Notes
  • HiFi-Stereo-Steuergerät mit Plattenwechsler Dual 1209; NF-Verstärker mit 2 Endstufen je 25 W (Sinus).
    Gehäuse in Nussbaum. Siehe auch Variante in Palisander, Teak oder Schleiflack, weiss.
  • Net weight (2.2 lb = 1 kg)
  • 18.5 kg / 40 lb 12 oz (40.749 lb)
  • Price in first year of sale
  • 1,698.00 DM
  • External source of data
  • Erb
