HiFi Record Player - Direct Drive Servo Control Modul 42P; Wega, (ID = 1258332) R-Player
Wega,: HiFi Record Player - Direct Drive Servo Control Modul 42P [R-Player] ID = 1258332 800x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model HiFi Record Player - Direct Drive Servo Control Modul 42P, Wega, Württembergische Radio-Ges. mbH; Stuttgart, Fellbach

Country:  Germany
Manufacturer / Brand:  Wega, Württembergische Radio-Ges. mbH; Stuttgart, Fellbach
alternative name

Württemb. Radio-Ges.mbH; Stuttgart
Year: 1978 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands - without
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: HiFi Record Player - Direct Drive Servo Control Modul 42P - Wega, Württembergische Radio-
Material Plastics (no bakelite or catalin)
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 450 x 150 x 395 inch / 11430 x 3810 x 10033 mm
Notes Komponente des Wega System Modul 42.
Plattenspieler mit 2 Geschwindigkeiten (33 und 45 U/min), Vollautomat, Direktantrieb. Tonabnehmer Magnetsystem Sony XL 15 oder Moving-Coil-System MC 42. Mechanik Übernahme von Sony. Design Hartmut Esslinger. Lieferbar in schwarz oder hellgrau.
Net weight (2.2 lb = 1 kg) 10 kg / 22 lb 0.4 oz (22.026 lb)
Price in first year of sale 998.00 DM
Mentioned in Wega Prospekt

Model page created by Gerhard Wickern. See "Data change" for further contributors.
