Studio 3229 HiFi; Wega, (ID = 785135) Radio
Wega,: Studio 3229 HiFi [Radio] ID = 785135 850x548
Select picture or schematic to display from thumbnails on the right and click for download.
For model Studio 3229 HiFi, Wega, Württembergische Radio-Ges. mbH; Stuttgart, Fellbach:
Q: Wega, Service-Unterlagen, 10/75

Country:  Germany
Manufacturer / Brand:  Wega, Württembergische Radio-Ges. mbH; Stuttgart, Fellbach
alternative name

Württemb. Radio-Ges.mbH; Stuttgart
Year: 1975/1976 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 29:
schematic requested
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 40 W (unknown quality)
from Radiomuseum.org Model: Studio 3229 HiFi - Wega, Württembergische Radio-
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 670 x 160 x 365 mm / 26.4 x 6.3 x 14.4 inch
Notes ICs: 5.
Wega Stereo-Kompaktgerät Studio 3229 HiFi.
Ausgangsleistung: 2× 20 W (Sinus); 4 Speichertasten für FM;
Phono-Chassis = Dual 1225 mit Magnetsystem Shure M75D.
Source of data Handbuch VDRG 1975/1976

Model page created by Bernd P. Kieck. See "Data change" for further contributors.
