• Country
• Germany

• Manufacturer / Brand
• Wenzl Hruby KG; Hamburg

• Year
• 1968

• Category
• Citizen Band Equipment

• Radiomuseum.org ID
• 225857

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 13

• Semiconductors

• Main principle
• Transceiver; ZF/IF 455 kHz

• Wave bands
• Short Wave (SW only)

• Power type and voltage
• Dry Batteries / 8 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2.75 inch = 7 cm

• Material
• Metal case

• from Radiomuseum.org
• Model: Fieldmaster TC-600 - Wenzl Hruby KG; Hamburg

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 90 x 210 x 40 mm / 3.5 x 8.3 x 1.6 inch

• Notes

• FTZ-Nr. K67/68
  Siehe auch Minix 50-T2.

  27 MHz Handsprechfunkgerät mit drei Kanälen, quarzgesteuert.

• Net weight (2.2 lb = 1 kg)
• 2.2 lb (2 lb 3.2 oz) / 0.999 kg

• Source of data
• -- Original-techn. papers.

• Author
• Model page created by Peter Ruecker. See "Data change" for further contributors.
