D-2624 Truetone early

D-2624 Truetone ; Western Auto Supply (ID = 92440) Radio

D-2624 Truetone ; Western Auto Supply (ID = 447014) Radio

D-2624 Truetone ; Western Auto Supply (ID = 447015) Radio

D-2624 Truetone ; Western Auto Supply (ID = 447016) Radio

D-2624 Truetone ; Western Auto Supply (ID = 447017) Radio

D-2624 Truetone ; Western Auto Supply (ID = 512931) Radio

D-2624 Truetone ; Western Auto Supply (ID = 512933) Radio

D-2624 Truetone ; Western Auto Supply (ID = 512935) Radio

D-2624 Truetone ; Western Auto Supply (ID = 512937) Radio
D-2624 Truetone ; Western Auto Supply (ID = 1176355) Radio D-2624 Truetone ; Western Auto Supply (ID = 447013) Radio
Use red slider bar for more.
D-2624 Truetone ; Western Auto Supply (ID = 1176355) Radio
Western Auto Supply: D-2624 Truetone [Radio] ID = 1176355 611x426
Select picture or schematic to display from thumbnails on the right and click for download.
For model D-2624 Truetone early, Western Auto Supply Co. (Truetone); Kansas City (MO):
Ebay Seller: kiwidave10 Item Number: 270914274242 Truetone D-2624 Front View

Country:  United States of America (USA)
Manufacturer / Brand:  Western Auto Supply Co. (Truetone); Kansas City (MO)
Year: 1946 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: 12SA7 12SK7 6SS7 12SQ7 12SJ7 35L6GT 35Z5GT
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage AC/DC-set / 117 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1.5 W (unknown quality)
from Radiomuseum.org Model: D-2624 Truetone [early] - Western Auto Supply Co.
Material Wooden case
Shape Tablemodel, with any shape - general.
Notes 4" x 6" PM elliptical speaker.
Photofact see under Trade name: Truetone.
Collectors' prices
External source of data Ernst Erb
Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 16 = ca. 1948 and before
Mentioned in Beitman Radio Diagrams, Vol. 08, 1948
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Set 2, Folder 462-6)


All listed radios etc. from Western Auto Supply Co. (Truetone); Kansas City (MO)
Here you find 789 models, 449 with images and 701 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.




rmXorg
