Audio Amplifier Type 13-B

Audio Amplifier Type 13-B; Western Electric (ID = 1610458) Ampl/Mixer Audio Amplifier Type 13-B; Western Electric (ID = 1610459) Ampl/Mixer
Audio Amplifier Type 13-B; Western Electric (ID = 1610460) Ampl/Mixer Audio Amplifier Type 13-B; Western Electric (ID = 1610461) Ampl/Mixer
Audio Amplifier Type 13-B; Western Electric (ID = 1610463) Ampl/Mixer Audio Amplifier Type 13-B; Western Electric (ID = 1610464) Ampl/Mixer
Audio Amplifier Type 13-B; Western Electric (ID = 1610466) Ampl/Mixer Audio Amplifier Type 13-B; Western Electric (ID = 1610472) Ampl/Mixer
Audio Amplifier Type 13-B; Western Electric (ID = 1610473) Ampl/Mixer Audio Amplifier Type 13-B; Western Electric (ID = 1610474) Ampl/Mixer
Use red slider bar for more.
Audio Amplifier Type 13-B; Western Electric (ID = 1610458) Ampl/Mixer
Western Electric: Audio Amplifier Type 13-B [Ampl/Mixer] ID = 1610458 933x736
Select picture or schematic to display from thumbnails on the right and click for download.
For model Audio Amplifier Type 13-B, Western Electric Company Inc.; New York (NY):
Ebay Item Number: 400658917084

Country:  United States of America (USA)
Manufacturer / Brand:  Western Electric Company Inc.; New York (NY)
Year: 1924 ?? Category: Audio Amplifier or -mixer
Valves / Tubes 4: 205D 205D 205D 205D
Main principle Audio-Amplification; 4 AF stage(s)
Wave bands - without
Details
Power type and voltage Storage and/or dry batteries
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: Audio Amplifier Type 13-B - Western Electric Company Inc.;
Material Wooden case
Shape Tablemodel, Box - most often with Lid (NOT slant panel).
Dimensions (WHD) 24 x 10 x 11 inch / 610 x 254 x 279 mm
Notes

Early 1920's Western Electric Type 13-B Audio Amplifier. The tube 205D is from 1924 (Tyne).

Net weight (2.2 lb = 1 kg) 35 lb (35 lb 0 oz) / 15.890 kg

Model page created by Alan Larsen. See "Data change" for further contributors.



All listed radios etc. from Western Electric Company Inc.; New York (NY)
Here you find 149 models, 124 with images and 27 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
