• Year
  • 1964
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 93492
    • alternative name: Westinghouse El. Int.

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 2
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Rec.Player+Audio.Amp+LS
  • Power type and voltage
  • Alternating Current supply (AC) / 120 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
  • from Radiomuseum.org
  • Model: H-111MP1 Ch= V-2537-3 - Westinghouse El. & Mfg. Co. -
  • Shape
  • Tablemodel, Box - most often with Lid (NOT slant panel).
  • Notes
  • The Westinghouse Model H-111MP1 is a portable AC Operated 2 Transistor Mono Amplifier with 4 Speed Record Player (not Record Changer). Has Qty(1) PM 4" speaker. Cabinet color is Charcoal. Westinghouse model H-111MP2 uses the same schematic and chassis, the difference being cabinet color.
  • Circuit diagram reference
  • Beitman Radio Diagrams Vol. 25, 1965
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Westinghouse Datasheet PH6062)
  • Author
  • Model page created by Egon Penker. See "Data change" for further contributors.
