H-196A Ch= V-2130-12DX
Westinghouse El. & Mfg. Co. - see also Canadian W.
- Country
- United States of America (USA)
- Manufacturer / Brand
- Westinghouse El. & Mfg. Co. - see also Canadian W.
- Year
- 1950 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 244505
-
- alternative name: Westinghouse El. Int.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 28
- Valves / Tubes
- 6AG5 6AG5 6C4 6BH6 6BH6 6BH6 6BH6 6AL5 12AT7 6AQ5 12AU7 12AX7 6AT6 6BJ6 6BH6 6T8 6AQ5 12AT7 12AU7 6AL5 6AC7 6AQ5 6BG6G 5V4G 1B3GT 5U4G 5V4G 10BP4
- Main principle
- Superheterodyne (common)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 110-120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9.5 inch = 24.1 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: H-196A Ch= V-2130-12DX - Westinghouse El. & Mfg. Co. -
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
-
TV-Receiver with 10 inch CRT b/w USA Standard.
Channels 2 thru 13.
- Mentioned in
- Photofact Folder, Howard W. SAMS (Vol.9/50 Date 1-50 84-13 Set 84 Folder 13)
