H-44AC1A V-2506-2 Chassis

H-44AC1A V-2506-2 Chassis; Westinghouse El. & (ID = 60755) R-Player

H-44AC1A V-2506-2 Chassis; Westinghouse El. & (ID = 511697) R-Player

H-44AC1A V-2506-2 Chassis; Westinghouse El. & (ID = 511698) R-Player
H-44AC1A V-2506-2 Chassis; Westinghouse El. & (ID = 511699) R-Player
Use red slider bar for more.
H-44AC1A V-2506-2 Chassis; Westinghouse El. & (ID = 511699) R-Player
Westinghouse El. &: H-44AC1A V-2506-2 Chassis [R-Player] ID = 511699 527x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model H-44AC1A V-2506-2 Chassis, Westinghouse El. & Mfg. Co. - see also Canadian W.:
Sams Photofact Folders

Country:  United States of America (USA)
Manufacturer / Brand:  Westinghouse El. & Mfg. Co. - see also Canadian W.
alternative name

Westinghouse El. Int.
Year: 1959 Category: Sound/Video Recorder and/or Player
Valves / Tubes 3: 12AV6 50C5 35W4
Main principle Audio-Amplification
Wave bands - without
Details Rec.Player+Audio.Amp+LS
Power type and voltage Alternating Current supply (AC) / 110 - 120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
Power out
from Radiomuseum.org Model: H-44AC1A V-2506-2 Chassis - Westinghouse El. & Mfg. Co. -
Shape Tablemodel, with any shape - general.
Source of data Beitman Radio Diagrams, Vol. 19, 1959
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Date 12-59, Set 466, Folder 16)

Model page created by Hinrich Grensemann † 15.5.16. See "Data change" for further contributors.
