H-70ACS3 Ch= V-2507-8

H-70ACS3 Ch= V-2507-8; Westinghouse El. & (ID = 149518) R-Player
Use red slider bar for more.
H-70ACS3 Ch= V-2507-8; Westinghouse El. & (ID = 149518) R-Player
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  United States of America (USA)
Manufacturer / Brand:  Westinghouse El. & Mfg. Co. - see also Canadian W.
alternative name

Westinghouse El. Int.
Year: 1960 ? Category: Sound/Video Recorder and/or Player
Valves / Tubes 3: 7025 6CU5 6CU5
Main principle Audio-Amplification
Details Rec.Player+Audio.Amp+LS
Power type and voltage Alternating Current supply (AC) / 117 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: H-70ACS3 Ch= V-2507-8 - Westinghouse El. & Mfg. Co. -
Notes Diode Rectifier.
Circuit diagram reference Beitman Radio Diagrams Vol. 21, 1961

Model page created by Egon Penker. See "Data change" for further contributors.
