H-794C21 Ch= V-2249-1 V-2187-1 Late

Westinghouse El. & Mfg. Co. - see also Canadian W.

Data

Forum

Pictures

Collections

Country
United States of America (USA)

Manufacturer / Brand
Westinghouse El. & Mfg. Co. - see also Canadian W.

Year
1953

Category
Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)

Radiomuseum.org ID
150554

- alternative name: Westinghouse El. Int.

Schematics

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 588821) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 588822) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266764) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266765) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266766) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266767) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266771) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266772) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266774) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266775) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266777) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266778) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266780) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266781) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266782) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266784) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266785) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266786) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266788) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266789) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266791) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266792) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266793) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266794) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266795) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266796) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266798) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266799) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266800) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1266801) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (3)

H-794C21 Ch= V-2249-1 V-2187-1; Westinghouse El. & (ID = 1238847) TV Radio — Westinghouse El. & H-794C21 Ch= V-2249-1 V-2187-1 (2)
Picture from Westinghouse datasheet

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Tubes
26

Main principle
Superhet with RF-stage

Wave bands
Wave Bands given in the notes.

Details
Changer (Record changer)

Power type and voltage
Alternating Current supply (AC) / 105-120 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 inch = 25.4 cm

Power out
6 W (unknown quality)

Material
Wooden case

from Radiomuseum.org
Model: H-794C21 Ch= V-2249-1 V-2187-1 [Late] - Westinghouse El. & Mfg. Co. -

Shape
Console with any shape - in general

Notes
The Westinghouse H-794C21 is a combination 21" b/w Television, AM receiver, Audio Amplifier, Record Changer and Speaker. The TV is equipped with US standard VHF tuner channels 2 thru 13. Uses TV chassis V-2249-1, AM chassis V-2187-1, VHF tuner V-11794-1 and picture tube 21YP4. Also uses record changer V-9840. AM tuning range is 540 to 1625 kHz. Cabinet is Mahogany. This late production model has various resistor and capacitor value changes along with a different power transformer. For service information, refer to Westinghouse model H-788C21 service notes and supplementary information.

Literature/Schematics (1)
Photofact Folder, Howard W. SAMS (Date 10-56, Set 333 & 334)

Literature/Schematics (2)
- - Manufacturers Literature (Westinghouse Datasheets RM3377 RM3370 RM4030)
