• Year
  • 1963
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 93478
    • alternative name: Westinghouse El. Int.

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 11
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Rec.Player+Audio.Amp+LS
  • Power type and voltage
  • Alternating Current supply (AC) / 108-130 Volt
  • Loudspeaker
  • 4 Loudspeakers
  • Power out
  • 10 W (unknown quality)
  • Material
  • Leather / canvas / plastic - over other material
  • from Radiomuseum.org
  • Model: H-91ACS1 Ch= V-2524-1 - Westinghouse El. & Mfg. Co. -
  • Shape
  • Tablemodel, Box - most often with Lid (NOT slant panel).
  • Notes
  • The Westinghouse Model H-91ACS1 is a portable AC Operated 11 Transistor Stereo Amplifier with 4 Speed Automatic Record Changer. Has Qty(2) PM 4" speakers and Qty(2) PM 6" speakers. Cabinet color is Midnight Charcoal. Uses Record Changer 670V027H05, with speeds of 16, 33, 45 and 78 RPM.
  • Circuit diagram reference
  • Beitman Radio Diagrams Vol. 25, 1965
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Westinghouse Datasheet PH6050)
  • Author
  • Model page created by Egon Penker. See "Data change" for further contributors.
