Jukebox 2250

Jukebox 2250 ; Wurlitzer Co., The (ID = 1506063) R-Player Jukebox 2250 ; Wurlitzer Co., The (ID = 1525989) R-Player
Jukebox 2250 ; Wurlitzer Co., The (ID = 1525991) R-Player Jukebox 2250 ; Wurlitzer Co., The (ID = 1525994) R-Player
Jukebox 2250 ; Wurlitzer Co., The (ID = 1525998) R-Player Jukebox 2250 ; Wurlitzer Co., The (ID = 1526004) R-Player
Jukebox 2250 ; Wurlitzer Co., The (ID = 1526007) R-Player Jukebox 2250 ; Wurlitzer Co., The (ID = 1526010) R-Player
Jukebox 2250 ; Wurlitzer Co., The (ID = 1526013) R-Player Jukebox 2250 ; Wurlitzer Co., The (ID = 1526015) R-Player
Use red slider bar for more.
Jukebox 2250 ; Wurlitzer Co., The (ID = 1506063) R-Player
Wurlitzer Co., The: Jukebox 2250 [R-Player] ID = 1506063 640x853
Select picture or schematic to display from thumbnails on the right and click for download.
For model Jukebox 2250, Wurlitzer Co., The Rudolph

Country:  United States of America (USA)
Manufacturer / Brand:  Wurlitzer Co., The Rudolph
Year: 1958 Category: Sound/Video Recorder and/or Player
Valves / Tubes 8: 12AU7 12AX7 6AN8 6AU6 12AX7 6L6G 6L6G 5U4G
Main principle Audio-Amplification
Wave bands - without
Details Jukebox-Coin operated Phonograph
Power type and voltage Alternating Current supply (AC) / 115 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Jukebox 2250 - Wurlitzer Co., The Rudolph
Material Various materials
Shape Console, Lowboy (legs < 50 %).
Dimensions (WHD) 870 x 1410 x 680 mm / 34.3 x 55.5 x 26.8 inch
Notes Jukebox mit 200 Wahlmöglichkeiten, 100 Singles mit 45 rpm.
Net weight (2.2 lb = 1 kg) 168 kg / 370 lb 0.7 oz (370.044 lb)
Mentioned in Musikboxen, Adams/ Lukas/ Mascke

Model page created by Nico Pokrant. See "Data change" for further contributors.



All listed radios etc. from Wurlitzer Co., The Rudolph
Here you find 221 models, 132 with images and 79 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
