High Fidelity Sound System 532

High Fidelity Sound System 532; Wurlitzer Co., The (ID = 2637372) Ampl/Mixer High Fidelity Sound System 532; Wurlitzer Co., The (ID = 2637375) Ampl/Mixer
High Fidelity Sound System 532; Wurlitzer Co., The (ID = 2637605) Ampl/Mixer High Fidelity Sound System 532; Wurlitzer Co., The (ID = 2637606) Ampl/Mixer
High Fidelity Sound System 532; Wurlitzer Co., The (ID = 2637607) Ampl/Mixer High Fidelity Sound System 532; Wurlitzer Co., The (ID = 2637608) Ampl/Mixer
High Fidelity Sound System 532; Wurlitzer Co., The (ID = 2637609) Ampl/Mixer High Fidelity Sound System 532; Wurlitzer Co., The (ID = 2637610) Ampl/Mixer
Use red slider bar for more.
High Fidelity Sound System 532; Wurlitzer Co., The (ID = 2637372) Ampl/Mixer
Wurlitzer Co., The: High Fidelity Sound System 532 [Ampl/Mixer] ID = 2637372 1400x894
Select picture or schematic to display from thumbnails on the right and click for download.
For model High Fidelity Sound System 532, Wurlitzer Co., The Rudolph:
aus ebay, #384063196671, mit Erlaubnis des Verkäufers jrcradio

Country:  United States of America (USA)
Manufacturer / Brand:  Wurlitzer Co., The Rudolph
Year: 1957 ? Category: Audio Amplifier or -mixer
Valves / Tubes 8: 12AU7 6AN8 12AX7 6AU6 12AX7 6L6G 6L6G 5U4GA or 5U4GB
Semiconductors (the count is only for transistors) Selenium-Rectifier
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 115 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: High Fidelity Sound System 532 - Wurlitzer Co., The Rudolph
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 16 x 6.25 x 12.5 inch / 406 x 159 x 318 mm
Notes

Amplifier for Wurlitzer mono jukebox 2100 and 2150.

Net weight (2.2 lb = 1 kg) 31 lb (31 lb 0 oz) / 14.074 kg

Model page created by Gottfried Silberhorn. See "Data change" for further contributors.



All listed radios etc. from Wurlitzer Co., The Rudolph
Here you find 222 models, 133 with images and 79 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
