• Country
• United States of America (USA)

• Manufacturer / Brand
• Wurlitzer Co., The Rudolph; North Tonawanda, NY

• Year
• 1931 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 137837

• Number of Tubes
• 6

• Valves / Tubes
• 24 24 24 24 45 80

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 110 Volt

• Loudspeaker
• Permanent or electro-dynamic (moving coil), system not known yet. / Ø 22 cm = 8.7 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Lyric Junior - Wurlitzer Co., The Rudolph;

• Shape
• Table-Cathedral-Type (upright, round top or gothic arch, not rounded edges only).

• Dimensions (WHD)
• 14.5 x 18 x 10.25 inch / 368 x 457 x 260 mm

• Notes
• Wurlitzer Lyric Junior;
  Three knobs, semi-cycle scale, chassis stamped "60 cycles T2".
  Early in 1929 the Rudolph Wurlitzer Manufacturing Company took over the production of Lyric Radios. The text is interesting: "In the combined plants of the All-American Mohawk Corporation and the Rudolph Wurlitzer Manufacturing Company, at North Tonawanda, New York, 93 % of the comlete LYRIC set is made. The same skill and workmanship that have made the mighty Wurlitzer organs famous is now responsible for the undisputed preëminence of LYRIC. Two hundred years of background and experience in the music indurstry enable this manufacturer to produce an outstanding radio such as the new 1931 LYRIC. ... "

• Net weight (2.2 lb = 1 kg)
• 12.7 kg / 27 lb 15.6 oz (27.974 lb)

• Source of data
• -- Collector info (Sammler)

• Author
• Model page created by a member from A. See "Data change" for further contributors.
