For model Active Antenna FRA-7700, Yaesu-Musen Co. Ltd.; Tokyo

Country:  Japan
Manufacturer / Brand:  Yaesu-Musen Co. Ltd.; Tokyo
Year: 1982 ? Category: Antenna (Aerial) or Coupler
Semiconductors (the count is only for transistors) 4:
Main principle Radio Frequency Amplification only
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Powered by external power supply or a main unit. / 9 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Active Antenna FRA-7700 - Yaesu-Musen Co. Ltd.; Tokyo
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 165 x 35 x 170 mm / 6.5 x 1.4 x 6.7 inch
Notes Yaesu Active-Antenna FRA-7700.
Covering 150 kHz - 30 MHz, matching the FRG-7700 shortwave receiver and other; can also be powered by connecting 9 V (- on Pin1 and + on Pin4 of german DIN type plug).
Aktivantenne in Tischgehäuse mit eingebauter Teleskopantenne passend zum Kurzwellenempfänger FRG-7700.
Net weight (2.2 lb = 1 kg) 0.5 kg / 1 lb 1.6 oz (1.101 lb)
Price in first year of sale 152.00 DM
