FRG-100

FRG-100; Yaesu-Musen Co. Ltd. (ID = 1378019) Amateur-R

FRG-100; Yaesu-Musen Co. Ltd. (ID = 1378021) Amateur-R

FRG-100; Yaesu-Musen Co. Ltd. (ID = 1378022) Amateur-R

FRG-100; Yaesu-Musen Co. Ltd. (ID = 1378024) Amateur-R

FRG-100; Yaesu-Musen Co. Ltd. (ID = 1378025) Amateur-R

FRG-100; Yaesu-Musen Co. Ltd. (ID = 1378027) Amateur-R

FRG-100; Yaesu-Musen Co. Ltd. (ID = 1378029) Amateur-R

FRG-100; Yaesu-Musen Co. Ltd. (ID = 1378030) Amateur-R

FRG-100; Yaesu-Musen Co. Ltd. (ID = 1378032) Amateur-R

FRG-100; Yaesu-Musen Co. Ltd. (ID = 1378033) Amateur-R
FRG-100; Yaesu-Musen Co. Ltd. (ID = 83398) Amateur-R FRG-100; Yaesu-Musen Co. Ltd. (ID = 1812439) Amateur-R
FRG-100; Yaesu-Musen Co. Ltd. (ID = 1812440) Amateur-R FRG-100; Yaesu-Musen Co. Ltd. (ID = 1812441) Amateur-R
FRG-100; Yaesu-Musen Co. Ltd. (ID = 1812443) Amateur-R FRG-100; Yaesu-Musen Co. Ltd. (ID = 1812445) Amateur-R
FRG-100; Yaesu-Musen Co. Ltd. (ID = 1812447) Amateur-R
Use red slider bar for more.
FRG-100; Yaesu-Musen Co. Ltd. (ID = 83398) Amateur-R
Yaesu-Musen Co. Ltd.: FRG-100 [Amateur-R] ID = 83398 933x467
Select picture or schematic to display from thumbnails on the right and click for download.
For model FRG-100, Yaesu-Musen Co. Ltd.; Tokyo:
FA 12/98

Country:  Japan
Manufacturer / Brand:  Yaesu-Musen Co. Ltd.; Tokyo
Year: 1993 Category: Amateur-Receiver (amateur bands, may include broadcast bands)
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superhet, double/triple conversion; ZF/IF 47210/455 kHz
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Powered by external power supply or a main unit. / DC 13.8 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: FRG-100 - Yaesu-Musen Co. Ltd.; Tokyo
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 238 x 93 x 243 mm / 9.4 x 3.7 x 9.6 inch
Notes Yaesu Communications-Receiver FRG-100.
Frequency range: 50 kHz to 30 MHz; Modes: AM, SSB, CW, FM optional; 52 memories; CAT.
Net weight (2.2 lb = 1 kg) 3 kg / 6 lb 9.7 oz (6.608 lb)
Price in first year of sale 1'300.00 DM
External source of data FA 12/98

Model page created by Bernd P. Kieck. See "Data change" for further contributors.



All listed radios etc. from Yaesu-Musen Co. Ltd.; Tokyo
Here you find 273 models, 260 with images and 92 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Yaesu-Musen Co. Ltd.: FRG-100
Threads: 1 | Posts: 1
Hits: 4457     Replies: 0
yaesu: FRG-100 / FRG-100B; ZF - Filtervarianten
Martin Bösch
15.Jan.08
  1 In Yaesu's Kurzwellenempfänger FRG-100 wurden initial in der 4 und 6 kHz - Position zwei ZF-Filter verwendet,
die relativ breit waren und sich in der Durchlassbreite kaum unterschieden. Diese wurden im Laufe der Produktion durch steilflankigere Filter von NTKK ersetzt.
In den USA wurde die Version mit den verbesserten Filtern als FRG-100B vermarktet, diese Bezeichnung findet sich allerdings nicht auf dem Gerät selbst.

FRG-100 erste Version
FRG - 100A
CFJ455K15 (2,7 KHz, Murata), CFW455I (4 kHz, Murata), CFW455H (6 kHz, Murata)
FRG-100 spätere Version
FRG - 100B
CFJ455K15 (2,7 KHz, Murata), LF-H2S 3Y (NTKK), LF-H6S 37 (NTKK), optional für FM: LF-H15S (15 kHz FM, NTKK)
Besten Dank für die Informationen und Beleuchtung der Hintergründe an Jürgen Martens und Bruno Schubarth. Martin Bösch
