FT-221R

FT-221R; Yaesu-Musen Co. Ltd. (ID = 1465201) Amat TRX FT-221R; Yaesu-Musen Co. Ltd. (ID = 794563) Amat TRX
FT-221R; Yaesu-Musen Co. Ltd. (ID = 1146728) Amat TRX FT-221R; Yaesu-Musen Co. Ltd. (ID = 1148823) Amat TRX
FT-221R; Yaesu-Musen Co. Ltd. (ID = 1148824) Amat TRX
Use red slider bar for more.
FT-221R; Yaesu-Musen Co. Ltd. (ID = 1465201) Amat TRX
Yaesu-Musen Co. Ltd.: FT-221R [Amat TRX] ID = 1465201 933x588
Select picture or schematic to display from thumbnails on the right and click for download.
For model FT-221R, Yaesu-Musen Co. Ltd.; Tokyo

Country:  Japan
Manufacturer / Brand:  Yaesu-Musen Co. Ltd.; Tokyo
Year: 1976–1978 ? Category: Amateur TRX: Transmitter/Receiver (and Transceiver)
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Transceiver; ZF/IF 10700/455 kHz
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Line / Batteries (any type) / 100-235 / 12 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 cm = 2.4 inch
Power out 2 W (unknown quality)
from Radiomuseum.org Model: FT-221R - Yaesu-Musen Co. Ltd.; Tokyo
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 280 x 125 x 295 mm / 11 x 4.9 x 11.6 inch
Notes

Yaesu VHF-Transceiver FT-221R. Covers 2-m-HAM band from 144 - 148 MHz in eight ranges. Modes SSB, CW, AM, FM. For more information see FT-221.

In Europe also sold under the Sommerkamp label.

The british Mutek-company sold a hight performance front-end board for this venerable RIG (Design by Ian White, G3SEK).

Net weight (2.2 lb = 1 kg) 8.5 kg / 18 lb 11.6 oz (18.722 lb)
Mentioned in -- Original-techn. papers.
