Select picture or schematic to display from thumbnails on the right and click for download.
For model FT-50R, Yaesu-Musen Co. Ltd.; Tokyo:
Yaesu´s brochure

Country:  Japan
Manufacturer / Brand:  Yaesu-Musen Co. Ltd.; Tokyo
Year: 1996 Category: Amateur TRX: Transmitter/Receiver (and Transceiver)
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superhet, double/triple conversion; ZF/IF 45100/455 kHz
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Storage and/or dry batteries / 4 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 0.5 W (unknown quality)
from Radiomuseum.org Model: FT-50R - Yaesu-Musen Co. Ltd.; Tokyo
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 57 x 99 x 30 mm / 2.2 x 3.9 x 1.2 inch
Notes YAESU VHF/UHF-FM-Handfunkgerät FT-50R.
Frequenzbereiche RX: 76···200 MHz, 300···540 MHz, 590···999 MHz; TX: 144···146 MHz, 430···440 MHz;
Pout bei 9,6 V: 5 W;
MIL-Standard, Doppelfrequenzdisplay mit alphanumerischer Darstellmöglichkeit einschl. Betriebsspannungsanzeige, 112 Speicherkanäle, externe Stromversorgung (4···16 V-) möglich.
Net weight (2.2 lb = 1 kg) 0.3 kg / 0 lb 10.6 oz (0.661 lb)
Price in first year of sale 719.00 DM
Mentioned in FA 6/96

Model page created by Iven Müller. See "Data change" for further contributors.
