FT-757GX

FT-757GX; Yaesu-Musen Co. Ltd. (ID = 755590) Amat TRX

FT-757GX; Yaesu-Musen Co. Ltd. (ID = 755591) Amat TRX

FT-757GX; Yaesu-Musen Co. Ltd. (ID = 755592) Amat TRX

FT-757GX; Yaesu-Musen Co. Ltd. (ID = 755593) Amat TRX

FT-757GX; Yaesu-Musen Co. Ltd. (ID = 755594) Amat TRX

FT-757GX; Yaesu-Musen Co. Ltd. (ID = 755595) Amat TRX

FT-757GX; Yaesu-Musen Co. Ltd. (ID = 755596) Amat TRX

FT-757GX; Yaesu-Musen Co. Ltd. (ID = 755597) Amat TRX

FT-757GX; Yaesu-Musen Co. Ltd. (ID = 755598) Amat TRX

FT-757GX; Yaesu-Musen Co. Ltd. (ID = 755599) Amat TRX
FT-757GX; Yaesu-Musen Co. Ltd. (ID = 72177) Amat TRX FT-757GX; Yaesu-Musen Co. Ltd. (ID = 87834) Amat TRX
FT-757GX; Yaesu-Musen Co. Ltd. (ID = 1449276) Amat TRX FT-757GX; Yaesu-Musen Co. Ltd. (ID = 1620211) Amat TRX
FT-757GX; Yaesu-Musen Co. Ltd. (ID = 2015980) Amat TRX
Use red slider bar for more.
FT-757GX; Yaesu-Musen Co. Ltd. (ID = 72177) Amat TRX
Yaesu-Musen Co. Ltd.: FT-757GX [Amat TRX] ID = 72177 506x292
Select picture or schematic to display from thumbnails on the right and click for download.
For model FT-757GX, Yaesu-Musen Co. Ltd.; Tokyo

Country:  Japan
Manufacturer / Brand:  Yaesu-Musen Co. Ltd.; Tokyo
Year: 1984 Category: Amateur TRX: Transmitter/Receiver (and Transceiver)
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superhet, double/triple conversion
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Storage and/or dry batteries / 11-15 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: FT-757GX - Yaesu-Musen Co. Ltd.; Tokyo
Material Metal case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 238 x 93 x 238 mm / 9.4 x 3.7 x 9.4 inch
Notes Yaesu Kurzwellen-Transceiver FT-757GX.
Frequenzbereich RX: 0,5-30 MHz, TX: 160-10 m inkl. WARC; Betriebsarten: SSB, CW, AM, AFSK, FM; elektronische Morsetaste; digitale Frequenzsteuerung mit optionalem Interface möglich; Sprachprozessor; Pout: 100 W (PEP), 25 W bei AM.
Net weight (2.2 lb = 1 kg) 5.2 kg / 11 lb 7.3 oz (11.454 lb)
Price in first year of sale 2'898.00 DM
Mentioned in RICOFUNK-Katalog 1984
Literature/Schematics (1) Funkschau (19/1984, S. 48, 49 / Beschreibung)

Model page created by Iven Müller. See "Data change" for further contributors.



All listed radios etc. from Yaesu-Musen Co. Ltd.; Tokyo
Here you find 263 models, 249 with images and 89 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
